Isolation CAN transceiver
CMT1052W
Isolation CAN transceiver
Isolation CAN transceiver
The CMT10XXX is an isolated CAN transceiver which fully compatible with the ISO11898-2 standard. The CMT10XXX integrated two channel digital isolators and a high reliability CAN transceiver. The digital isolator is silicon oxide isolation based on CMOSTEK capacity isolation technology. The high integrated solution can help to simplify system design and improve reliability. The CMT10XXX device is safty certified by UL1577 support5 kVrms insulation withstand voltages, while providing high electromagnetic immunity and low emissions. The data rate of the CMT10XXX is up to 5Mbps. The CMT10XXX provides thermal protection and transmit data dominant time out function.
Applications：
Transmission Speed：
5MHzIsolation Voltage：
5kVCMTI：
150kV/usSurge Class：
8kVpkESD Rating：
8KVOperating Voltage：
2.5V-5.5VOperating Mode：
/Temperature Range：
-40°C~125°CPackage：
SOW16
